Customized High Precision Quality CE CNC Lathe Machine Ck6166

Overview Milling Customized High Precision Quality CE CNC Lathe Machine Ck6166 Product Description Product Specification

Overview

Model NO.	CK6166
Automatic Grade	Automatic
Setting Mode	Floor-type
Precision	High Precision
Certification	CE, ISO 9001
Condition	New
Tool Post Stations	32*32mm
Power of Main Motor	11 Kw
Spindle Speed	27~135 55~270 160~805 325~1630 R/Min
Spindle Bore	105mm or 80mm
Max Swing Over Bed	530mm
Transport Package	Export Wooden Case(Heat Treated)
Specification	CE, ISO9001, SGS
Trademark	KD
Origin	Zhejiang China
HS Code	8458110000
Production Capacity	1100sets/ Year

Milling Customized High Precision Quality CE CNC Lathe Machine Ck6166

Product Description

Product Specifications

ITEMS	CK6166	CK6156
Max. swing over bed	Ø 660 mm	Ø 560 mm
Max. swing over carriage	Ø 430 mm	Ø 330 mm
Width of bed	405 mm
Maximum turned length	750/1000/1500/2000/3000 mm
Max. turning length	650/900/1400/1900/2900mm
Spindle nose	D8	A2-8
Spindle bore	Ø 105 mm	Ø 80 mm
Cone hole diameter and taper of spindle hole	Ø 113 1: 20	MT. No. 7
Steps of spindle speed(Manual)	4 (Variable Within Each Step )
Range of spindle speed	27~135 55~270 160~805 325~1630 r/min
Rapid feed for Axis Z	10m /min
Rapid feed for Axis X	8 m /min
Max. travel of Axis Z	720/970/1270/1970/2970mm
Max. travel of Axis X	365 mm	320 mm
Min. input	0.001 mm
Tool post stations	4-ways or 6-ways
Tool cross section	32× 32 mm
External diameter	Ø 75 mm
Taper of bore	MT. No. 5
Max. Traverse	150 mm
Power of main motor	11 KW	7.5 KW
Power of cooling pump	90W
Overall dimensions(L× W× H)	2250/2500/3000/3500× 1250× 1580 mm	2250/2500/3000/3500/4500× 1200× 1520 mm
Net weight	2800/3100/3700/4300/5300 kg	2700/3000/3500/4000/4600 kg
