Double Side Planer CH204h Planning Machine
Features of double side planer1.Features:1.The machine body is casing lathe and processed by CNC center, which is strong
Basic Info.
Model NO. | CH204H |
Spindle Speed | >5000rpm |
Process Type | Medium-Sized Processing |
Certification | CE, ISO |
Top &Bottom Spindle Motor Power | 7.5/7.5kw |
Feeding Speed | 0-16m/Min |
Total Weight | 2450kg |
Feeding Motor Power | 2.2kw |
Cutting Shaft Diameter | 101mm |
Working Thickness | 200mm |
Transport Package | PE Film |
Specification | CH204F |
Trademark | CHANCSMAC |
Origin | China |
Production Capacity | 20 Sets/Month |
Product Description
Features of double side planer1.Features:1.The machine body is casing lathe and processed by CNC center, which is strong and durable. Can make sure machine running in good condition and precision working.2. High precision main spindle and imported bearing can make sure the wood surface in high quality and accuracy.3. Working table is chromate treatment, smooth, flat, harder and durable4.The bottom spindle can be pulled out easily to replace the blades. Safer, easier and more convenient.5. Electrical components international famous brand like OMRON, SCHNEIDER as well as other brands, which can make sure machine safety running and easy maintenance.Specification:2.Parameters:Model | CH204F | CH204H | CH206F | CH206H |
Working width | 430mm | 430mm | 630mm | 630mm |
Working thickness | 200mm | 200mm | 200mm | 200mm |
Mini. Working length | 260mm | 260mm | 260mm | 260mm |
Max. Cutting depth (Top spindle) | 8mm | 8mm | 8mm | 8mm |
Max. Cutting depth (Bottom spindle) | 5mm | 5mm | 5mm | 5mm |
Cutting shaft diameter | Ø101mm | Ø101mm | Ø101mm | Ø101mm |
Spindle speed | 5000r/min | 5000r/min | 5000r/min | 5000r/min |
Feeding speed | 4-16m/min | 0-16m/min | 4-16m/min | 0-16m/min |
Top & Bottom spindle motor power | 7.5/7.5kw | 7.5/7.5kw | 11/7.5kw | 11/7.5kw |
Feeding motor power | 2.2kw | 2.2kw | 2.2kw | 3kw |
Total weight | 2100kg | 2450kg | 2500kg | 2800kg |
3.Detailed Images:4.Factory:5.FAQ:List some questions customers care about, if you have more quotations, please feel free to contact us1. Q: What's the MOQ? R: One set will be ok.2. Q: Provide customized machine Yes or NO? R: Yes. We have professional designers and engineers to supply customized machines. 3. Q: What is payment terms? R: 30%T/T in advance, the balance paid before shipment after inspection.4. Q: What is the warranty time? R: One year.
